Stirrer Overhead IKA EUROSTAR 60 Digital

Stock:

1 - 9

Add to Favourites

Downloads

Description

Note: Special Pricing for Stock Only!

Universally used strong laboratory stirrer for quantities up to 40L (H2O). It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/30 - 2000 rpm. Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions. Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically. This guarantees a constant speed even with changes in viscosities of the sample.

Features and Benefits:

Digital speed display
Infinitely adjustable speed
Push-through agitator shafts
Overload protection
Short-term overload operation
Slim casing
Quiet operation
Error code display

Technical Data:

Stirring Quantity Max (H20)	40L
Motor Rating Input	176W
Motor Rating Output	126W
Motor principle	Brushless DC
Speed Display	7 segment LED
Speed Range	0/30 - 2,000rpm
Viscosity Max	50,000mPas
Output Max at Stirring Shaft	126W
Permissible On Time	100%
Torque Max at Stirring Shaft	60Ncm
Speed Adjustment	Stepless
Setting Accuracy Speed	+/-1rpm
Deviation of Speed Measurement	+/-3rpm
Stirring Element Fastening	Chuck
Chuck Range Diameter	0.5 - 10mm
Hollow Shaft, inner diameter	11mm
Hollow Shaft (Push-through - when stopped)	Yes
Fastening on Stand	Extension arm
Extension arm diameter	16mm
Extension arm length	220mm
Speed Control	Electronic
Nominal Torque	0.6Nm
Housing material	alu-cast coating / thermoplastic ploymer
Dimensions (W x H x D)	86 x 248 x 208mm
Weight	3.9kg
Protection class according to DIN EN 60529	IP42
